Product Description
Features and Application
This product is special cable used in power supply connection of town planning projects of urban water
supply,sewage, rod, bridge,tunnel,subway,square and ,environmental facilities etc, and used as
power-control resistant, chemical erosion resistant, ozone aging resistant, UV radiation property
and can resist termite, rat plague, dampness, water ,mildew, fire (low smoke, low halogen or
halogen free and low smoke),the usage life is 40-50 years.
Type Designation and Notes
Type | Designation |
XFGTNS-FBY | Soluble polyamide insulation organic silicon elastomer sheath termite resistant special wire and cable |
XFGTNS22-FBY | Soluble polyamide insulation organic silicon elastomer sheath steel tape armored termite resistant special wire and cable |
XFGTNSP-FBY | Soluble polyamide insulation organic silicon elastomer sheath Cu net shielded armored termite resistant special wire and cable |
XFGTGS | Soluble rubber insulation organic silicon elastomer sheath erosion resistant and cold resistant special wire and cable |
XFGTGSP | Soluble rubber insulation organic silicon elastomer coating Cu screen shielded erosion resistant and cold resistant special wire and cable |
XFGTGS22 | Soluble rubber insulation organic silicon elastomer sheath steel tape armored erosion resistant and cold resistant special wire and cable |
XFGTGS | Soluble rubber insulation organic silicon elastomer sheath water type erosion resistant and watertight special wire and cable |
XFKTGSMP | Fluoroplastic insulation organic silicon mixing elastomer silicon rubber sheath water type erosion resistant and watertight shield special wire and cable |
Model Notes
Code | Definition | Code | Definition |
GT | Series code | P | Conner screen sheath |
G | Silicone rubber | M | Watertight |
N | Soluble polyamide | FBY | Termite resistant |
S | Organic silicone mixing elastomer | 22 | Steel tape armored |
32 | Small gauge steel wire armored |
Usage Characteristics
1. Rated Voltage Uo/U: 0.6/1KV,450/750V,220/380V.
2. Operating temperature :
XFGTNS-FBY,XFGTNS22-FBY,XFGTNSP-FBY :40℃~250℃
XFGTGS,XFGTGS22,XFGTGSP,XFGTGSM:60℃~150℃
3.Minimum bend radius: Cable without armored coating shall be not less than 6 times of outer cable diameter.
Cable with armored coating shall be no less than 8 times of outer cable diameter.
Technology Index and characteristics
Packaging & Shipping
In coils, wooden drums, steel drums or steel-wooden drums.
We could producing according to the customers' requirements.
Welcome your request for any quotations!
