1 x 240 mm2 Single-core 24 KV Aluminium conductor XLPE insulated PVC sheathed feeder cables

Product Description

Type

Name

Application

Conductor

YJV

YJY

YJLV

XLPE Insulated,PVC or PE S heathed Power Cable

For laying in door,tunnel,channel and underground.Unable to bear external mechanical force,but bear the traction force during laid.

YJV22

YJV23

YJLV22

YJLV23

XLPE Insulated,Steel Tape Armoured,PVC or PE Sheathed Power Cable

For laying in tunels in door,tunnel,channel and underground.Able to bear external mechanical force,but unable to bear large pulling force.

YJV32

YJV33

YJLV32

YJLV33

XLPE Insulated,Fine Steel Wire Armoured,PVC or PE Sheathed Power Cable

For laying in shaft with large difference of level.Able to bear external mechanical force,and moderable pulling force.

YJV42

YJV43

YJLV42

YJLV43

XLPE Insulate,Thick Steel Wire Armoured,PVC or PE Sheathed Power Cable

Able to bear positive pressure and pulling force

1 x 240 mm2 Single-core 24 KV Aluminium conductor XLPE insulated PVC sheathed feeder cables aluinium wire armoured power cable Application?

Power cables for power networks, underground, outdoors and in cable ducting.
Standards:BS6622
Conductor:Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
Conductor screen:Semi-conducting material
Insulation:XLPE (Cross-Linked Polyethylene) Type GP8 to BS7655
Insulation Screen:Semi-conducting material
Metallic Screen:Individual and overall copper tape screen to BS6622
Filler:PETP (Polyethylene Terephthalate) fibres
Separator:Binding tape
Bedding:PVC (Polyvinyl Chloride) Type TM1 to BS7655
Armouring:Single Core: Aluminium Wire Armoured (AWA)

Multi-core: Steel Wire Armoured (SWA)
Sheath:PVC (Polyvinyl Chloride) Type TM1 to BS7655
Colour:Red or Black
Voltage Rating:19000/33000V
Temperature Rating:0°C to +90°C

U0/Um(kv) No.of Core	1st class	0.6/1	1.8/3	3.6/6	6/10	8.7/15	12/20	18/30	21/35
U0/Um(kv) No.of Core	2nd class	1/1	3/3	6/6	8.7/10	12/15	18/20	-	26/35
1 Core	Section area(mm2)	1.5-800	25-800	25-800	25-800	35-800	50-800	50-800	50-800
2 Core	Section Area(mm2)	1.5-185	/	/	/	/	/	/	/
3 Core	Section area(mm2)	1.5-400	25-400	25-400	25-400	35-400	50-400	50-400	50-400
4 Core	Section Area(mm2)	2.5-400	25-400	/	/	/	/	/	/
5 Core	Section area(mm2)	2.5-400	25-400	/	/	/	/	/	/

1 x 240 mm2 Single-core 24 KV Aluminium conductor XLPE insulated PVC sheathed feeder cables aluinium wire armoured power cable Application?

1 low voltage cable power cable
Low voltage (0.6/1 kv)
single core or multi-core
copper or aluminium conductor
pvc inusulation
steel tape armored or galvanized steel wire armored or unarmored
pvc outer sheath
power cable.
2.2 medium voltage cabel power cable
Voltage grade is up to 35kv,
cross-section area can be up to 1000 sqmm (copper or aluminiun conductor).
Conductor long-time operating temperature is 90 degrees.
In short circuit, conductor highest temperature should be not more than 250 degrees.
1kv-35 kv
multi-cores
copper or aluminium conductor
xlpe insulation<span style="font-family: Arial;color: rgb(51, 51, 51);letter-spacing: 0;fon
